QR-Codes
Briefing:
A QR code (quick-response code) is a type of two-dimensional A QR Code (quick-response code) is a type of two dimensional matrix barcode, invented in 1994, by Japanese company Denso Wave for labelling automobile parts. A barcode is a machine-readable optical image that contains information specific to the labelled item. In practice, QR codes contain data for a locator, an identifier, and a website visitor tracking. To efficiently store data, QR codes use four standardized modes of encoding (i) numeric, (ii) alphanumeric, (iii) byte or binary, and (iv) kanji.
A QR code consists of black squares arranged in a square grid on a white background, including some fiducial markers which can be read by an imaging device such as a camera, and processed using Reed-Solomon error correction until the image can be appropriately interpreted. The required data is then extracted from patterns that are present in both horizontal and vertical components of the image.
The QR labelling system was applied beyond the automobile industry due to its fast readability and greater storage capacity compared to standard UPC barcodes. Applications include product tracking, item identification, time tracking, document management, and general marketing.
Design:
Unlike the older, one-dimensional barcodes that were designed to be mechanically scanned by a narrow beam of light, a QR code is detected by a 2-dimensional digital image sensor and then digitally analyzed by a programmed processor. The processor locates the three distinctive squares at the corners of the QR code image, using a smaller square (or multiple squares) near the fourth corner to normalize the image for size, orientation, and angle of viewing. The small dots throughout the QR code are then converted to binary numbers and validated with an error-correcting algorithm.
Applications:
In 2017, Singapore created a taskforce including their Government Agencies such as the Monetary Authority of Singapore and Infocomm Media Development Authority to spearhead a system for e-payments using standardized QR code specifications. These specific dimensions are specialized for Singapore’s market.
The e-payment system, Singapore Quick Response Code (SGQR), essentially merges various QR codes into one label that can be used by both parties in the payment system. This allows for various banking apps to facilitate payments between multiple customers and a merchant that displays the single QR code.
A single SDQR label contains e-payments and combines multiple payment options. Once consumers spot the SGQR label, they will be able to scan it and see which payment options the merchant accepts. The SGQR scheme is co-owned by MAS and IMDA.
Website login
QR codes can be used to log into websites: a QR code is shown on the login page on a computer screen, and when a registered user scans it with a verified smartphone, they will automatically be logged in. Authentication is performed by the smartphone, which contacts the server. Google tested such a login method in January 2012.
Mobile ticket
There is a system whereby a QR code can be displayed on a device such as a smartphone and used as an admission ticket. Its use is common for J1 league and Nippon professional baseball tickets in Japan. In some cases, rights can be transferred via the Internet.
Restaurant ordering
Restaurants can present a QR code near the front door or at the table allowing guests to view an online menu, or even redirect them to an online ordering website or app, allowing them to order and/or possibly pay for their meal without having to use a cashier or waiter. QR codes can also link to daily or weekly specials that are not printed on the standardized menus, and enable the establishment to update the entire menu without needing to print copies. At table-serve restaurants, QR codes enable guests to order and pay for their meals without a waiter involved – the QR code contains the table number so servers know where to bring the food. This application has grown especially since the need for social distancing during the 2020 COVID 19 pandemic prompted reduced contact between service staff and customers.
Joining a Wi‑Fi network
By specifying the SSID, encryption type, password/passphrase, and if the SSID is hidden or not, mobile device users can quickly scan and join networks without having to manually enter the data. A MeCard-like format is supported by Android and iOS 11+.
Common format: WIFI:S:<SSID>;T:<WEP|WPA|nopass>;P:<PASSWORD>;H:<true|false|blank>;;
Sample: WIFI:S:MySSID;T:WPA;P:MyPassW0rd;;
Funerary use
A QR code can link to an obituary and can be placed on a headstone. In 2008, Ishinokoe in Yamanashi Prefecture, Japan began to sell tombstones with QR codes produced by IT DeSign, where the code leads to a virtual grave site of the deceased. Other companies, such as Wisconsin-based Interactive Headstones, have also begun implementing QR codes into tombstones. In 2014, the Jewish Cemetery of La Paz in Uruguay began implementing QR codes for tombstones.
Electronic authentication
QR codes are also used to generate time-based one-time passwords (TOTP) for electronic authentication.
Loyalty programs
QR codes have been used by various retail outlets that have loyalty programs. Sometimes these programs are accessed with an app that is loaded onto a phone and includes a process triggered by a QR code scan. The QR codes for loyalty programs tend to be found printed on the receipt for a purchase or on the products themselves. Users in these schemes collect award points by scanning a code.
Counterfeit detection
Serialised QR codes have been used by brands and governments to let consumers, retailers and distributors verify the authenticity of the products and help with detecting counterfeit products, as part of a brand protection program. However, the security level of a regular QR code is limited since QR codes printed on original products are easily reproduced on fake products, even though the analysis of data generated as a result of QR code scanning can be used to detect counterfeiting and illicit activity. A higher security level can be attained by embedding a digital watermark or copy detection pattern into the image of the QR code. This makes the QR code more secure against counterfeiting attempts, and fake products that contain a counterfeit QR code can be detected by scanning the secure QR code with a specific app (even though the QR code message itself is valid).
The treaty regulating apostilles (documents bearing a seal of authenticity), has been updated to allow for the issuance of digital apostilles by countries; a digital apostille is a PDF document with a cryptographic signature containing a QR code for a canonical URL of the original document, allowing users to verify the apostille from a printed version of the document.
Product tracing
Different studies have been made to assess the effectiveness of QR codes as a means of conveying labelling information and their use as part of a food traceability system. In a field experiment, it was found that when provided free access to a smartphone with QR code scanning app, 52.6% of participants would use it to access labelling information. A study made in South Korea showed that consumers appreciate QR code used in food traceability system, as they provide detailed information about food, as well as information that helps them in their purchasing decision. If QR codes are serialised, consumers can access a web page showing the supply chain for each ingredient, as well as information specific to each related batch, including meat processors and manufacturers, which helps address the concerns they have about the origin of their food.
COVID-19 pandemic
| Barcode | QR code |
|---|---|
| Barcode was created and developed by Norman Joseph Woodland in 1952. | QR code was created and developed by Masahiro Hara in 1994. |
| Bar code and be represented in 2 types − one dimensional or 2 dimensional. | QR Code is one type. |
| Barcode stores numbers in a printed format where the computer can understand. | QR code is a two dimensional printed representation of data used to scan and retrieve data. |
| Barcode in different stores to track all purchased products and also in hospitals for tracking the patient record etc. | QR code used at super markets and different stores to track all purchased products and also used in hospitals, cinema halls etc. |
| A barcode is represented in the form of bars and spaces of varying width which can be read with an optical barcode scanner. | QR code is based on Morse code. |
| The storage capacity of Barcode is more than 100 bytes. | QR code storage capacity is 2 kilobytes |
| It requires less storage when compared to QR code. | It requires more storage when compared to Barcode. |
| Barcode is cost effective | QR code is cost effective but it is easily to deploy |
| Barcode is one way communication | At a time only one QR code can be read. |
| Barcode usage is more in super packets and stores where the item's information and rate is tracked and maintained. | In all stores and public places to scan the tickets, QR code usage is very high. |
